SPECIFICATION
- Housing :
- Steel sheet thickness of 0.5-0.8 mm. And all metal parts are rust-proofed after fabrication to prevent any corrosion (zine phosphate) and finished with high-grade epoxy polyester powder coating.
- Reflector :
- Double side aluminum reflector 99.90% purity anodized aluminum reflector to provide total reflectance of TR 87-95% mirror-finish, parabolic reflectors machined to provide optimum optical performance for maximum high-output-ratio. OR Double side steel reflector with high-grade epoxy polyester powder coating.
- Diffuser :
- Is made of prismatic acrylic with 2.0-3.0 mm. Thickness Option diffuser: (**)
- Prismatic = PM , Opal = MU , Stipple = ES , Clear = CS
- Lamp holder :
- Rotary lock (G13 or G5) lamp holder certified by TIS NO.344-2549.
- Starter holder :
- Rotary lock certified by TIS NO.344-2549.
- Wire :
- Thw size 0.5-1.0 sqmm. 70๐c - 105๐c Certified by TIS NO.11-2553.
Products
|
Model No |
No. of Lamps |
Dimension |
|
|
Ask
|
MAM-A346 |
3 x 36w. T8 |
600 mm. x 1,200 mm. |
|
|
Ask
|
MAP-L114MU-AL |
1 X 14w. T5 |
100 mm x 580 mm. |
|
|
Ask
|
MAP-L128MU-AL |
1 X 28w. T5 |
100 mm x 1,180 mm. |
|
|
Ask
|
MAP-Q114CS-AL |
1 X 14w. T5 |
85 mm. x 580 mm. |
|
|
Ask
|
MAP-Q120CS-AL |
1 x 18w. T8 |
115 mm. x 615 mm. |
|
|
Ask
|
MAP-Q128CS-AL |
1 X 28w. T5 |
85 mm. x 1,180 mm. |
|
|
Ask
|
MAP-Q140CS-AL |
1 x 36w. T8 |
115 mm. x 1,225 mm. |
|
|
Ask
|
M-COM120-AL |
1 x 18w. T8 |
198 mm. x 675 mm. |
|
|
Ask
|
M-COM120-CS-AL |
1 x 18w. T8 |
198 mm. x 675 mm. |
|
|
Ask
|
M-COM140-AL |
1 x 36w. T8 |
198 mm. x 1,285 mm. |
|
|
Ask
|
MET-RB25 |
1 x Lamp E27 |
156 mm. x 183 mm. |
|
|
Ask
|
MET-XR-V2 |
4 x 10w. |
827 mm. x 537 mm. |
|
|
Ask
|
MHP128MU |
1 x 28w. T5 |
100 mm. x 1,180 mm. |
|
|
Ask
|
MHP140PM |
1 x 36w. T8 |
100 mm. x 1,235 mm. |
|
|
Ask
|
MHT120PM-SW |
1 x 18w. T8 |
131 mm. x 618 mm. |
|
|
Ask
|
MHT140PM-SW |
1 x 36w. T8 |
131 mm. x 1,230 mm. |
|
|
Ask
|
MPM220 |
2 x 36w. T8 |
275 mm. x 1,250 mm. |
|
|
Ask
|
MRM-A246 |
2 x 36w. T8 |
600 mm. x 1,200 mm. |
|
|
Ask
|
MRP-A246PM-AL |
2 x 36w. T8 |
600 mm. x 1,200 mm. |
|
|
Ask
|
MRP-A346PM-AL |
3 x 36w. T8 |
600 mm. x 1,200 mm. |
|
|
Ask
|
MW240D6 |
2 x 36 w. , 6 x PAR 30 |
255 mm. x 2,217 mm. |
|
|
Ask
|
MW-TOP11410MU-AL |
1 x 14w. T5 |
100 mm. x 575 mm. |
|
