Channel Fitting

Channel Fitting with Mattel Reflector or aluminum Reflector

SPECIFICATION

Housing :
Steel sheet thickness of 0.5-0.8 mm. And all metal parts are rust-proofed after fabrication to prevent any corrosion (zine phosphate) and finished with high-grade epoxy polyester powder coating.
Cover :
Double side aluminum reflector 99.90% purity anodized aluminum reflector to provide total reflectance of TR 87-95% mirror-finish, parabolic reflectors machined to provide optimum optical performance for maximum high-output-ratio. Or Double side steel reflector with high-grade epoxy polyester powder coating.
Lamp holder :
Rotary lock (G13) lamp holder certified by TISNO.344-2549.
Starter holder
Rotary lock certified by TIS NO.344-2549.
Wire
Thw size 0.5-1.0 sqmm.70 ํc-105 ํc certified by TIS NO.11-2553.

Products
Model No No. of Lamps Dimension
Ask MCF128 1 x 28w. T5 40 mm. x 1,175 mm.
Ask MCF128AL 1 x 28w. T5 40 mm. x 1,175 mm.
Ask MCF140 1 x 36w. T8 52 mm. x 1,223 mm.
Ask MCF140AL 1 x 36w. T8 52 mm. x 1,223 mm.
Ask MCF228 2 x 28w. T8 80 mm. x 1,175 mm.
Ask MCF228-AL 2 x 28w. T5 80 mm. x 1,175 mm.
Ask MCF240 2 x 36w. T8 150 mm. x 1,223 mm.
Ask MCF240T 2 x 36w. T8 100 mm. x 1,223 mm.
Ask MPU1281CS 1 x 28w. T5 155 mm. x 1,180 mm.
Ask MPU140CS 1 x 36w. T8 155 mm. x 1,180 mm.
Ask MPU142CS-AL 1 x 36w. T8 200 mm. x 1,170 mm.
Ask MPU2281CS 2 x 28w. T5 155 mm. x 1,180 mm.
Ask MPU240CS 2 x 36w. T8 200 mm. x 1,235 mm.
Ask MPU240PM 2 x 36w. T8 200 mm. x 1,235 mm.
Ask MWG120 1 x 18w. T8 65 mm. x 625 mm.
Ask MWG140 1 x 36w. T8 65 mm. x 1,235 mm.
