SPECIFICATION

Housing :
Steel sheet thickness of 0.5-0.8 mm. And all metal parts are rust-proofed after fabrication to prevent any corrosion (zine phosphate) and finished with high-grade epoxy polyester powder coating.
Reflector :
Double side aluminum reflector 99.90% purity anodized aluminum reflector to provide total reflectance of TR 87-95% mirror-finish, parabolic reflectors machined to provide optimum optical performance for maximum high-output-ratio. OR Double side steel reflector with high-grade epoxy polyester powder coating.
Diffuser :
Is made of prismatic acrylic with 2.0-3.0 mm. Thickness Option diffuser: (**)
Prismatic = PM , Opal = MU , Stipple = ES , Clear = CS
Lamp holder :
Rotary lock (G13 or G5) lamp holder certified by TIS NO.344-2549.
Starter holder :
Rotary lock certified by TIS NO.344-2549.
Wire :
Thw size 0.5-1.0 sqmm. 70๐c - 105๐c Certified by TIS NO.11-2553.

Products
Model No No. of Lamps Dimension
Ask MAM-A346 3 x 36w. T8 600 mm. x 1,200 mm.
Ask MAP-L114MU-AL 1 X 14w. T5 100 mm x 580 mm.
Ask MAP-L128MU-AL 1 X 28w. T5 100 mm x 1,180 mm.
Ask MAP-Q114CS-AL 1 X 14w. T5 85 mm. x 580 mm.
Ask MAP-Q120CS-AL 1 x 18w. T8 115 mm. x 615 mm.
Ask MAP-Q128CS-AL 1 X 28w. T5 85 mm. x 1,180 mm.
Ask MAP-Q140CS-AL 1 x 36w. T8 115 mm. x 1,225 mm.
Ask M-COM120-AL 1 x 18w. T8 198 mm. x 675 mm.
Ask M-COM120-CS-AL 1 x 18w. T8 198 mm. x 675 mm.
Ask M-COM140-AL 1 x 36w. T8 198 mm. x 1,285 mm.
Ask MET-RB25 1 x Lamp E27 156 mm. x 183 mm.
Ask MET-XR-V2 4 x 10w. 827 mm. x 537 mm.
Ask MHP128MU 1 x 28w. T5 100 mm. x 1,180 mm.
Ask MHP140PM 1 x 36w. T8 100 mm. x 1,235 mm.
Ask MHT120PM-SW 1 x 18w. T8 131 mm. x 618 mm.
Ask MHT140PM-SW 1 x 36w. T8 131 mm. x 1,230 mm.
Ask MPM220 2 x 36w. T8 275 mm. x 1,250 mm.
Ask MRM-A246 2 x 36w. T8 600 mm. x 1,200 mm.
Ask MRP-A246PM-AL 2 x 36w. T8 600 mm. x 1,200 mm.
Ask MRP-A346PM-AL 3 x 36w. T8 600 mm. x 1,200 mm.
Ask MW240D6 2 x 36 w. , 6 x PAR 30 255 mm. x 2,217 mm.
Ask MW-TOP11410MU-AL 1 x 14w. T5 100 mm. x 575 mm.
